5SL42507RC 50 A Two Pole MCB
As per Siemens's policy
on orders above Rs. 1,000
- MCBs are used to protect plants in buildings and for industrial applications.
- The devices can be used as main switches for the disconnection or isolation of plants.
- The devices are approved for use according to IEC standards for systems up to 250/440 V AC.
|Type of Product||Miniature Circuit Breakers|
|Rated Current (A)||50 A|
|Insulation Voltage||250/440 V AC|
|Relative humidity||95 %|
|Applied Connection Torque||2 - 3 Nm|
|Standard||IS/IEC 60898-1 : 2002|
|Features||Highly effective touch protection against accidental contact . Ergonomically designed, with a user friendly lever for effortless switching . MCB with patented unique SLR (Slide Latch-Release) feature for tool free removal from DIN rail. It also allows individual MCBs to be removed from bus mounted assembly . Enables firm mounting of Bus bar together with wire and front access of wires for safer installation . To highlight exact switching position, easily recognizable color coded ON-OFF is embedded on the attractive grey lever|
|Module Width (18 mm/module)||2|
|Breaking Capacity (kA)||7.5 kA|
|Ambient Temperature||-25°C to +55°C|
|Rated Voltage||240/415 V|
