| Type of Product | Wirewound Resistor |
| Mounting Type | Chassis Mount |
| Width | 40 mm |
| Length | 165 mm |
Type of Product |
Wirewound Resistor |
Mounting Type |
Chassis Mount |
Width |
40 mm |
Length |
165 mm |
Height |
20 mm |
Resistance |
39 Ohms |
Tolerance |
0.05 |
Voltage Rating |
600 VAC, 850 VDC |
Temperature coefficient |
200 PPM / C |
Power Rating |
100 W |
Maximum Operating Temperature |
+ 250 C |
Minimum Operating Temperature |
- 25 C |
Termination Style |
Wire Lead Termination |
Name of Manufacturer/Packer/Importer |
TE Connectivity / CGS |
Manufacturer Part Number |
2-2176504-0 |
Ordering ID |
279-2-2176504-0 |
RoHS Compliant |
RoHS Compliant |
Packaging Type |
Bulk |
