| Type of Product | TVS Diode |
| Dimension | 4.6 x 2.92 x 2.1 mm |
| Height | 2.1 mm |
| Width | 2.92 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
TVS Diode |
Dimension |
4.6 x 2.92 x 2.1 mm |
Height |
2.1 mm |
Width |
2.92 mm |
Country of Origin |
United Kingdom |
Pack of |
5000 Pcs |
Mounting Type |
Surface Mount |
Maximum Operating Temperature |
+150°C |
Minimum Operating Temperature |
-55°C |
Length |
4.6 mm |
Name of Manufacturer/Packer/Importer |
Diodes Zetex Semiconductors Limited |
Package Type |
DO-214AC (SMA) |
Pin Count |
2 |
Manufacturer Part Number |
SMAJ12A-13-F |
Test Current |
1 mA |
Diode Configuration |
Single |
Number of Elements Per Chip |
1 |
Direction Type |
Uni-Directional |
Minimum Breakdown Voltage |
13.3V |
Maximum Clamping Voltage |
19.9V |
Peak Pulse Power Dissipation |
400W |
Maximum Reverse Leakage Current |
5 µA |
Maximum Reverse Stand-off Voltage |
12V |
Maximum Peak Pulse Current |
20.1A |
