| Type of Product | UC Series cam switch |
| Model No | UC-249-Y1B-C2011 |
| Country of Origin | Japan |
| Name of Manufacturer/Packer/Importer | IDEC Corporation |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
UC Series cam switch |
Model No |
UC-249-Y1B-C2011 |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
IDEC Corporation |
Contact Configuration |
Double Breaking Slow Action, With Two Contacts Per Stage |
Protection Class |
IP40(IEC 60529) |
Contact Material |
Silver |
Handle Color |
Black (Approximately N1.5) |
Monotaro ID |
48030930 |
Import Country |
Direct Import from Japan |
Operation Ambient Temperature (°C) |
-25-50°C (No Icing) |
Insulation_Resistance (MΩ) |
100 MΩ or more (DC500V mega) |
Rated Carrying Current (A) |
10A |
Rated Insulation Voltage (V) |
600 V |
Operating Ambient Humidity (% RH) |
45 To 85 (No Condensation) |
Electrical Life (10,000 Times) |
over 20 |
Notch Angle |
90° |
Operation method |
Each Position Stop Type |
Number of Notches |
4 |
Mechanical Life (10,000 Times) |
Over 50 |
No. of Tiers |
2 (Contact Block) |
Withstand voltage (V / min) |
Between live parts and non-live parts: AC2500 |
Circuits |
C2011 |
Storage Temperature Range |
-40 To 80°C (No Icing) |
Handle Type |
Φ30 Y handle |
