Generic 12V 2-Channel Relay Module with Opto-coupler H/L Level Trigger

Features
Type of Product : 12V 2-Channel Relay Module with Opto-coupler H/L Level Trigger
Model No : 2 channel relay board
More Details
Check serviceability at your Pincode:
Use Code:
View all Offers
  • Warranty
    As per GENERIC's policy
  • 100% Original
    Products
  • Free Shipping
    on orders above Rs. 1,000
  • Secure
    Payments
  • 100% buyer
    Protection
  • EARN
    IB Cash

Module description


  • Maximum load on normally open pin: AC 250V/10A, DC 30V/10A.
  • Trigger current 5mA
  • Module can be set high level or low level trigger by jumper wire
  • Power indicator light (green), relay status indicator light (red)
  • Module size: 50 x 41 x 18.5mm

  • Module interface specifications


  • DC+ : DC power supply positive pole
  • DC- : DC power supply negative pole
  • IN1 : channel 1 signal triggering pin
  • IN2 : channel 2 signal triggering pin

  • Relay output


  • Normally closed pin (NC1) : channel 1 relay normally closed pin
  • Common pin (COM1) : channel 1 relay common pin
  • Normally opened pin (NO1) : channel 1 relay normally opened pin
  • Normally closed pin (NC2) : channel 2 relay normally closed pin
  • Common pin (COM2) : channel 2 relay common pin
  • Normally opened pin (NO2) : channel 2 relay normally opened pin

  • High or low level trigger option


  • S1:It is option switch for channel 1 relay
  • S2:It is option switch for channel 2 relay
  • It is low level trigger if COM pin connect to LOW pin
  • It is high level trigger if COM connect to High
  • Buy Generic 12V 2-Channel Relay Module with Opto-coupler H/L Level Trigger online in India at wholesale rates. If you have been looking for Generic 12V 2-Channel Relay Module with Opto-coupler H/L Level Trigger dealers, your search ends here as you can get the best Generic 12V 2-Channel Relay Module with Opto-coupler H/L Level Trigger distributors in top cities such as Delhi NCR, Mumbai, Chennai, Bengaluru, Kolkata, Chennai, Pune, Jaipur, Hyderabad and Ahmedabad. You can purchase Generic 12V 2-Channel Relay Module with Opto-coupler H/L Level Trigger of the finest quality and rest assured to get the best in terms of both durability and performance. If you are bothered about the Generic 12V 2-Channel Relay Module with Opto-coupler H/L Level Trigger prices, you can be totally sure to get the best rates as Industrybuying brings you genuine Generic 12V 2-Channel Relay Module with Opto-coupler H/L Level Trigger rates and quality assured products only from the best of brands with exclusive brand discounts you won’t find anywhere else. Procure Generic 12V 2-Channel Relay Module with Opto-coupler H/L Level Trigger today and avail the best offers on your purchase.

    1,266 (GST inclusive price)
    1,073 (GST extra)
    i
    Additional Details
    List Price 1,073
    Discount 0.00%
    Price 1,073
    GST 18.00%
    Update Quantity
    Minimum Order Quanity- 1 Piece
    Bulk quantity Discounts!! Clear Selection
    Select
    Quantity
    Discount
    Price per piece
    4 - 9
    2.94 %
    Rs. 1042
    10 - 19
    3.68 %
    Rs. 1034
    20 - 49
    4.42 %
    Rs. 1026
    50+
    4.91 %
    Rs. 1021
