| Model No | BW125JAL-3P050K |
| Type of Product | General Purpose Circuit Breaker |
| Country of Origin | Japan |
| Trip button | Included |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Model No |
BW125JAL-3P050K |
Type of Product |
General Purpose Circuit Breaker |
Country of Origin |
Japan |
Trip button |
Included |
Monotaro ID |
50076257 |
Connection Type |
Surface type (screw terminal) |
No. of Pole |
3 Pole |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Series |
G-TWIN |
Import Country |
Direct Import from Japan |
Rated Breaking Capacity (kA) |
JIS C 8201-2-2 Ann.2：(AC 440/415/400/380 V)30/15-(AC 240/230 V)50/25-(AC 100 V)50/25 |
Rated Current (A) |
50 |
Rated Operating Voltage (V) |
AC 100-230-440 shared |
Operating Time |
(High speed / time extension type) 0.1s / 0.4s / 1s / 2s switching (maximum) |
Phase / Wire Type |
1Φ3 W, 3Φ3 W, 1Φ2 W |
Rated Frequency (Hz) |
50-60 |
Rated Impulse Withstand Voltage (kV) |
6 |
Dimension B (Φmm) |
155 |
Dimension C (Φmm) |
68 mm |
Overcurrent Tripper Type |
Thermal-electromagnetic |
Inertia Non-Operation Time |
(High speed / time extension type) 0 / 0.2 / 0.5 / 1 Sec |
Dimension A (Φmm) |
90 |
Dimension D (Φmm) |
95 mm |
Reverse Connection |
AC 240 V or less is possible |
Rated Sensitivity Current (mA) |
100/200/500/1000 switching |
Pollution Degree (Environment to Use) |
3 |
Type of Resetting |
Manual Reset |
No. of Elements |
3E |
