| Model No | CP30FM-3P0P1WB |
| Type of Product | Circuit Protector |
| Country of Origin | Japan |
| Monotaro ID | 64016384 |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Model No |
CP30FM-3P0P1WB |
Type of Product |
Circuit Protector |
Country of Origin |
Japan |
Monotaro ID |
64016384 |
No. of Pole |
3 Pole |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Series |
CP30F |
Import Country |
Direct Import from Japan |
Operating Patterns |
Medium Speed Type |
Rated Breaking Capacity (kA) |
2.5(at AC 250 V) |
Rated Current (A) |
0.1 |
Mass (g) |
About 240 |
Terminal Screw |
Main circuit: M5 screw (25A or more), M4 screw (20A or less) Screw up / Auxiliary circuit: M3.5 screw Self-up |
Rated Operating Voltage (V) |
AC 250 |
Operating Ambient Temperature |
-10 to +60℃ (however, no freezing or condensation) |
Reference Ambient Temperature |
40℃ |
Contact Configuration |
1B |
Withstand Voltage |
2000 V AC for 1 minute |
Tripper Type |
No delay device |
Allowable Relative Humidity (%) |
85 or less |
Type of Sign |
(Surface type) For both M4 screws and IEC rails |
Switch Type |
1 standard load / auxiliary switch |
Storage Temperature |
-40 to +60℃ (however, no freezing or condensation) |
Rated Insulation Voltage (V) |
AC 250 |
Shock Resistance (m/s²) |
294 |
