| Voltage | 100 V |
| Type of Product | AC Servo Motor |
| Model No | R88M-K40030L-BS2 |
| Series | G5 series |
Voltage |
100 V |
Type of Product |
AC Servo Motor |
Model No |
R88M-K40030L-BS2 |
Series |
G5 series |
Motor Type |
Cylinder Type |
Monotaro ID |
39094982 |
With or Without Brake |
Included |
Rating |
Continuous |
Type |
Servomotor |
Rotational Speed |
3000 RPM |
Protection Class |
IP67 (Excluding Shaft Penetration, Motor Connector, And Encoder Connector Connection Pins) |
Material |
(Heat Sink)Al |
Applicable Standard |
(UL Standard) UL1004-1 (CSA Standard) CSA 22.2 No.100 |
Power Supply |
Alternating Current |
Dimensions s (mm) |
14 |
Motor Capacity |
400 W |
Country of Origin |
China |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Output (kW) |
0.4 kW |
Withstand Voltage |
Between Power Terminal And Fg: AC 1500 (Voltage 100V/200 V) Between Power Terminal And Fg: AC 1800 (Voltage 400V) Between Brake Terminal And Fg: AC 1000 |
Mass (Kg) |
About 1.6 |
Power Consumption (W) |
9 (At 20 ° C) |
Dimension (mm) |
130×120×T12 |
Maximum Torque (Nm) |
(Instant) 3.8 |
Import Country |
Direct Import from Japan |
Input Type |
Pulse Train Input Type |
Insulation Class |
F Class |
