| Type of Product | AC Servo Motor |
| Model No | R88M-G40030H-BS2 |
| Monotaro ID | 39094124 |
| With or Without Brake | Included |
Type of Product |
AC Servo Motor |
Model No |
R88M-G40030H-BS2 |
Monotaro ID |
39094124 |
With or Without Brake |
Included |
Rating |
Continuous |
Type |
Servomotor |
Rotational Speed |
3000 RPM |
Protection Class |
IP65 (Excluding Shaft Penetration) |
Material |
(Heat Sink)Al |
Applicable Standard |
(EC Directive) (Low Voltage Directive) IEC60034-5:2001 (UL Standard) UL1004 File No.E179189<>br (cUL Standard) cUL 22.2, No.100 |
Power Supply |
Alternating Current |
Motor Capacity |
400 W |
Country of Origin |
CHINA |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Output (kW) |
0.4 |
Type of Sign |
Flange Mounting |
Mass (Kg) |
1.7 |
Power Consumption (W) |
9 (At 20 ° C) |
Dimension (mm) |
(Heat-Resistant Plate) 130 × 120 × T12 |
Structure |
Fully Closed Self Cooling Type |
Maximum Torque (Nm) |
(Instant) 3.6 |
Import Country |
Direct Import from Japan |
