| Model No | 37103-4080-G00 FL |
| Color | Purple |
| Material | Body: PBT, Base cover: 66 nylon, Top cover: Polycarbonate, Contact: Copper alloy |
| Type of Product | Wire Mount Plug |
Model No |
37103-4080-G00 FL |
Color |
Purple |
Material |
Body: PBT, Base cover: 66 nylon, Top cover: Polycarbonate, Contact: Copper alloy |
Type of Product |
Wire Mount Plug |
Rated Current (A) |
Up to 3.0 |
Country of Origin |
Japan |
No. of Pole |
3 poles |
Monotaro ID |
25909986 |
Operating Temperature Range |
-20 to 85℃ (when 1A is applied) -20 to 75℃ (when 2A is applied) -20 to 60℃ (when 3A is applied) *No condensation or water droplets |
Name of Manufacturer/Packer/Importer |
3M Japan Limited |
RoHS Directive |
Correspondence |
Trusco Part No. |
199-9148 |
Import Country |
Direct Import from Japan |
Applicable Connector |
Mini clamp board mount socket 372xx-xxxx-00x○○, Mini clamp wire mount socket 373xx-xxxx-0x0FL |
Applicable Wire Range AWG |
#20 to 28(0.08 to 0.50 mm2), ♯26-28 |
Conductor Diameter |
Suitable wire: 0.6 to 2.0 mm |
Finished Outer Diameter (mm) |
0.6-0.8 |
