| Model No | LD200-3P-34 |
| Material | Insulator: PPSorLCPBlack |
| No. Of Pin | 3 |
| Type of Product | Laser Diode Socket |
Model No |
LD200-3P-34 |
Material |
Insulator: PPSorLCPBlack |
No. Of Pin |
3 |
Type of Product |
Laser Diode Socket |
Rated Current (A) |
2 |
Country of Origin |
Japan |
Contact Material |
Copper Alloy, Au plating over Ni |
Monotaro ID |
12795985 |
Withstand Voltage |
AC500Vrms 1min |
Operating Temperature Range |
-45 to +150 ℃ |
Pack of |
10 Pcs |
Name of Manufacturer/Packer/Importer |
Japan Connect Industry |
RoHS Directive |
Correspondence |
Insulation Resistance (MOhm) |
500/min |
Contact Resistance (ohm) |
15 mΩ/max |
Dimension F (Φmm) |
0.51 |
Dimension d |
1.9 mm |
Sleeve Material |
Brass, Au plating over Ni |
Cell Spacing (mm) |
2 |
Import Country |
Direct Import from Japan |
Suitable Size |
Lead: Φ0.48 to 0.42/Φ0.0189" to 0.0165" |
Dimension L (mm) |
3.4 |
