| Model No | BSF-21T-P1.4 |
| Material | Phosphor bronze / tin plating (reflow treatment) |
| Type of Product | Socket Contact |
| Rated Current (A) | (Maximum) 7 |
Model No |
BSF-21T-P1.4 |
Material |
Phosphor bronze / tin plating (reflow treatment) |
Type of Product |
Socket Contact |
Rated Current (A) |
(Maximum) 7 |
Rated Voltage |
MAx300V |
Country of Origin |
Japan |
Monotaro ID |
49019887 |
Insulation Resistance |
1000 mΩ or more |
Withstand Voltage |
1500V AC / 1 minute |
Operating Temperature Range |
-25°C to + 90°C (including temperature rise) |
Pack of |
100 Pcs |
Name of Manufacturer/Packer/Importer |
Japan Solderless Terminals Mfg. Co., Ltd. |
Mass (g) |
17 |
RoHS Directive |
Correspondence |
Suitable Wire |
0.3 to 0.75 mm², AWG#22 to #18 |
Trusco Part No. |
421-8353 |
Import Country |
Direct Import from Japan |
Wire Sheath Outer Diameter (mm) |
1.5 to 2.2 |
