| Model No | NWPC-502-P22 |
| Type | Round type |
| Type of Product | Connector Straight Plug |
| Rated Current (A) | 80 |
Model No |
NWPC-502-P22 |
Type |
Round type |
Type of Product |
Connector Straight Plug |
Rated Current (A) |
80 |
Country of Origin |
Japan |
Shape |
Straight |
No. of Pole |
2 |
Monotaro ID |
74036926 |
Connection Type |
Screw |
Contact Type |
Female |
Operating Temperature Range |
-40 to +85℃ |
Name of Manufacturer/Packer/Importer |
Nanaboshi Scientific Research Institute Co., Ltd. |
Rated Voltage (V) |
500 |
Withstand voltage (V / min) |
3000 |
RoHS Directive |
Correspondence |
Insulator Material |
Synthetic resin |
Specifications |
Positive core (equipment side) |
Insulation Resistance (MOhm) |
5000 |
Contact Resistance (ohm) |
1 mΩ or less |
Import Country |
Direct Import from Japan |
Shell Size |
50 |
Material (Gasket) |
Synthetic rubber |
Connector Shape |
Plug |
Conductor Cross Section Area |
30 mm² |
Suitable Cable Outer Dia. (Φmm) |
21.1 to 23.0 |
