| Model No | NWPC6010ADF35 |
| Type | Round type |
| Type of Product | Metal Connector Relay Adapter |
| Rated Current (A) | 30 |
Model No |
NWPC6010ADF35 |
Type |
Round type |
Type of Product |
Metal Connector Relay Adapter |
Rated Current (A) |
30 |
Country of Origin |
Japan |
Shape |
Straight |
No. of Pole |
1 |
Connector Type |
NWPC6010PM35 |
Monotaro ID |
18728378 |
Connection Type |
Screw |
Contact Type |
Female |
Name of Manufacturer/Packer/Importer |
Nanaboshi Scientific Research Institute Co., Ltd. |
Rated Voltage (V) |
250 |
RoHS Directive |
Correspondence |
Insulator Material |
Synthetic resin |
Import Country |
Direct Import from Japan |
Waterproof Specifications |
IP-x6 equivalent |
Lock |
Screw lock method |
Shell Size |
60 |
Material/Finish |
Shell: brass / chrome plating, insulator: synthetic resin, contact: copper alloy / silver plating, packing: synthetic rubber |
Material (Gasket) |
Synthetic rubber |
Connection Method |
Solder |
Watertight or Waterproof |
35 |
