| Model No | NAW207ADFK8 |
| Type | Round type |
| Type of Product | One-Touch Lock Connector Relay Adapter |
| Rated Current (A) | 10 |
Model No |
NAW207ADFK8 |
Type |
Round type |
Type of Product |
One-Touch Lock Connector Relay Adapter |
Rated Current (A) |
10 |
Country of Origin |
Japan |
Shape |
Straight |
No. of Pole |
7 |
Connector Type |
NAW207PMK8, NAW207PM8 |
Monotaro ID |
18684506 |
Connection Type |
Screw |
Contact Type |
Male |
Operating Temperature Range |
-25 to +85℃ |
Name of Manufacturer/Packer/Importer |
Nanaboshi Scientific Research Institute Co., Ltd. |
Rated Voltage (V) |
250 |
Withstand voltage (V / min) |
1000 |
RoHS Directive |
Correspondence |
Insulator Material |
Synthetic resin |
Import Country |
Direct Import from Japan |
Waterproof Specifications |
IP-67 equivalent |
Lock |
One-touch lock method |
Shell Size |
20 |
Material/Finish |
Shell: Zinc alloy / Special treatment, Insulator: Synthetic resin, Contact: Copper alloy / Silver plating, Packing: Synthetic rubber |
Material (Gasket) |
Synthetic rubber |
Connection Method |
Solder |
Watertight or Waterproof |
8 |
