| Model No | NJW-2012-AdF10 |
| Type | AdF adapter |
| Rating | 5 Amp 250 V |
| Type of Product | Connector Relay Adapter |
Model No |
NJW-2012-AdF10 |
Type |
AdF adapter |
Rating |
5 Amp 250 V |
Type of Product |
Connector Relay Adapter |
Country of Origin |
Japan |
Shape |
Inverted core |
Contact Material |
Copper alloy / silver plating |
No. of Contacts |
12 |
Monotaro ID |
10365521 |
Contact Type |
Reverse core (Socket Contact) |
Withstand Voltage |
1000 V |
Operating Temperature Range |
-25 to +85℃ |
Name of Manufacturer/Packer/Importer |
Nanaboshi Scientific Research Institute Co., Ltd. |
Insulator Material |
Synthetic resin |
Specifications |
Reverse core (power supply side) |
Insulation Resistance (MOhm) |
1000 |
Contact Resistance (ohm) |
5 mΩ or less |
Import Country |
Direct Import from Japan |
Shell Size |
20 |
Material (Gasket) |
Synthetic rubber |
Wire Connection |
Soldering |
Conductor Cross Section Area |
0.5 mm² |
Material (Shell) / Finish |
Zinc alloy/special chemical treatment |
Suitable Cable Outer Dia. (Φmm) |
8.6 to 10.5 |
