| Model No | XR2P-2041 |
| Type of Product | IC Socket |
| Rated Current (A) | 1 |
| Part No | 64-3404-62 |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Model No |
XR2P-2041 |
Type of Product |
IC Socket |
Rated Current (A) |
1 |
Part No |
64-3404-62 |
Country of Origin |
Japan |
Contact Material |
(Contact / Terminal) Brass / Nickel base + Gold plating (0.25 μm) |
No. of Pole |
20 |
Monotaro ID |
39106094 |
Operating Temperature Range |
-55~+125℃ (no freezing at low temperatures) |
Pack of |
1 Pcs |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Terminal Shape |
DIP straight terminal |
Rated Voltage (V) |
AC300 |
Dimension A (Φmm) |
48.26 |
Withstand voltage (V / min) |
AC1000 (leakage current 1mA or less) |
Insulation Resistance (MOhm) |
10³ mohm or more (at 500 V DC) |
Contact Resistance (ohm) |
20 or less (20mV or less, 100mA or less) |
Plate Material |
PCT resin (UL94V-0) / black |
Import Country |
Direct Import from Japan |
