Ships within 19 days
Model No
No. of Pole
View
View
View
View
| Model No | XR2A-2463-N |
| Type of Product | IC Socket Open Frame Type |
| Rated Current (A) | 1 |
| Part No | 64-3402-97 |
Model No |
XR2A-2463-N |
Type of Product |
IC Socket Open Frame Type |
Rated Current (A) |
1 |
Part No |
64-3402-97 |
Standard |
UL standard (File No.E103202) |
Suitable For |
IC: Flat lead (thickness 0.29 ± 0.09 mm × width 0.46 ± 0.08mm: maximum diagonal size 0.56mm), round lead (maximum Φ0.53mm, minimum Φ0.41mm) |
Country of Origin |
Japan |
No. of Pole |
24 Pole |
Monotaro ID |
46596304 |
Withstand Voltage |
1000 V AC, 1 min (leakage current 1 mA or less) |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Terminal Shape |
Dip Terminal |
Rated Voltage (V) |
AC 300 |
Dimension A (Φmm) |
10.16 |
Operation Ambient Temperature (°C) |
-55 to +125 (no freezing at low temperatures) |
Specifications |
RoHS compliant |
Insulation Resistance (MOhm) |
10³ Or More (At 500 V DC) |
Contact Resistance (ohm) |
20 mΩ or Less (20 mV mΩ or Less, 100 mA mΩ or Less) |
Insertion / Removal Durability (Times) |
50 |
Dimension B (Φmm) |
27.94 |
Material (Foot Plate) |
Glass-filled PBT resin (UL94V-0) / Black |
Processing (Inner, Contact) |
Nickel base + gold plating 0.25 μm |
Material (Outer Sleeve) |
Brass |
Processing (Outer, Sleeve) |
Nickel base + gold flash plating |
Import Country |
Direct Import from Japan |
