| Model No | XJ8B-0711 |
| Type of Product | Short-Circuit Plug Single Row Type |
| Rated Current (A) | 2 |
| Part No | 64-3399-76 |
Model No |
XJ8B-0711 |
Type of Product |
Short-Circuit Plug Single Row Type |
Rated Current (A) |
2 |
Part No |
64-3399-76 |
Standard |
RoHS directive, UL standard (File No.E103202) |
Country of Origin |
JAPAN |
Shape |
Single row plug type for short circuit (low profile) |
Contact Material |
Brass |
No. of Pole |
7 |
Housing Material |
PPS resin with glass (UL94V-0) / Black |
Monotaro ID |
46695652 |
Withstand Voltage |
700 V AC, 1 min (leakage current 1 mA or less) |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Surface Treatment |
Nickel base gold plating (0.15 μm) |
Rated Voltage (V) |
AC 300 |
Dimension A (Φmm) |
20.3 |
Operation Ambient Temperature (°C) |
-55 to +105 (no freezing at low temperatures) |
Insulation Resistance (MOhm) |
10³ Or More (At 500 V DC) |
Total Removal Force |
0.39 N or more (with short-circuit plug) |
Total Insertion Force |
1.96N or less (with short-circuit dedicated plug) |
Contact Resistance (ohm) |
20 mΩ or Less (20 mV mΩ or Less, 100 mA mΩ or Less) |
Insertion / Removal Durability (Times) |
50 |
Dimension B (Φmm) |
17.78 |
Import Country |
Direct Import from Japan |
