Ships within 25 days
View
View
View
View
| Model No | XR2T-0811-N |
| Type | Gold plating 0.25 μm |
| Type of Product | IC Socket Open Frame Type |
| Rated Current (A) | 1 |
Model No |
XR2T-0811-N |
Type |
Gold plating 0.25 μm |
Type of Product |
IC Socket Open Frame Type |
Rated Current (A) |
1 |
Part No |
64-3404-70 |
Country of Origin |
JAPAN |
Contact Material |
Beryllium copper / nickel base Gold plating |
No. of Pole |
8 |
Monotaro ID |
46597686 |
Operating Temperature Range |
-55 to +125 ℃ (no freezing at low temperatures) |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Terminal Shape |
Dip terminal |
Rated Voltage (V) |
AC 300 |
Dimension A (Φmm) |
7.62 |
Withstand voltage (V / min) |
AC 1000 (leakage current 1 mA or less) |
Insulation Resistance (MOhm) |
10³ Or More (At 500 V DC) |
Contact Resistance (ohm) |
20 mΩ or Less (20 mV mΩ or Less, 100 mA mΩ or Less) |
Insertion / Removal Durability (Times) |
50 |
Dimension B (Φmm) |
7.62 |
Material (Foot Plate) |
PBT resin (UL94V-0) / black |
Material (Outer Sleeve) |
Brass / nickel base Gold flash plating |
Single Removal Force |
0.64 N or more (with Φ0.433 test gauge) |
Single insertion force |
3.92 N or less (with Φ0.432 test gauge) |
Carrier Material |
Aluminum |
Import Country |
Direct Import from Japan |
