Ships within 19 days
View
View
View
View
| Model No | XG8B-0134 |
| Type of Product | Original Plug |
| Part No | 64-3395-48 |
| Standard | RoHS directive, ML standard (MIL-C-83503), UL standard (file No.E103202) |
Model No |
XG8B-0134 |
Type of Product |
Original Plug |
Part No |
64-3395-48 |
Standard |
RoHS directive, ML standard (MIL-C-83503), UL standard (file No.E103202) |
Country of Origin |
Japan |
Contact Material |
(Contact part) Brass / nickel base gold plating (0.15 μm), (Terminal part) Brass / nickel base tin plating (2.0 μm) |
No. of Pole |
100 |
Monotaro ID |
39103662 |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Terminal Shape |
2-row type, L-shaped terminal |
Rated Voltage (V) |
AC 300 |
Withstand voltage (V / min) |
AC 650 (leakage current 1 mA or less) |
Operation Ambient Temperature (°C) |
-55 to +105 (no freezing at low temperatures) |
Insulation Resistance (MOhm) |
10³ Or More (At 500 V DC) |
Contact Resistance (ohm) |
20 mΩ or Less (20 mV mΩ or Less, 100 mA mΩ or Less) Value when mated with XG5M-N |
Material (Foot Plate) |
Glass-filled PBT resin (UL94V-0) / Black |
Import Country |
Direct Import from Japan |
