Ships within 25 days
View
View
View
View
| Outer ring type | Flat |
| Shield Shape | Open type |
| Race ring shape | Angular Contact Ball Bearing |
| Material | High Carbon Steel |
Outer ring type |
Flat |
Shield Shape |
Open type |
Race ring shape |
Angular Contact Ball Bearing |
Material |
High Carbon Steel |
Outer Diameter D (Φmm) |
72 |
Rolling element material |
High Carbon Chromium Bearing Steel |
Contact Angle |
15° (α) |
JIS grade |
0 |
Basic static load rating Cor (N) |
40000 |
Width B (mm) |
17 |
Basic dynamic load rating Cr (N) |
49500 |
Monotaro ID |
47957646 |
Type of Product |
Flash Ground Angular Contact Ball Bearing 7200 Type (Combination of 2) |
Model No |
7207CDU |
Mass (g) |
295 |
Load direction |
Radial |
Chamfer Dimension r1 (mm) |
0.6 (minimum) |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Fujikoshi Corporation |
Chamfer Dimension r (mm) |
1.1 (minimum) |
Allowable Speed (min-1[r.p.m]) Grease Lubrication |
12000 |
Allowable Speed (min-1 [r.p.m]) Oil Lubrication |
17000 |
Inner Diameter (mm) |
35 |
