| Outer ring type | Flat |
| No. of Track Trains | Single row |
| Shield Shape | Open type |
| Race ring shape | Angular Contact Ball Bearing |
Outer ring type |
Flat |
No. of Track Trains |
Single row |
Shield Shape |
Open type |
Race ring shape |
Angular Contact Ball Bearing |
Material |
High Carbon Steel |
Outer Diameter D (Φmm) |
130 |
Contact Angle |
15° (α) |
JIS grade |
4 |
Basic static load rating Cor (N) |
59000 |
Mass (g) single row |
960 |
Width B (mm) |
22 |
Basic dynamic load rating Cr (N) |
60500 |
Monotaro ID |
47957165 |
Type of Product |
Single Row Angular Contact Ball Bearings 7000 Type |
Model No |
7017C-P4 |
Mass (g) |
960 |
Load direction |
Radial |
Chamfer Dimension r1 (mm) |
0.6 (minimum) |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Fujikoshi Corporation |
Chamfer Dimension r (mm) |
1.1 (minimum) |
Allowable Speed (min-1[r.p.m]) Grease Lubrication |
7400 |
Allowable Speed (min-1 [r.p.m]) Oil Lubrication |
10000 |
Inner Diameter (mm) |
85 |
