| Race ring shape | Angular Contact Ball Bearing |
| Outer Diameter D (Φmm) | 180 |
| Contact Angle | 15° |
| Width B (mm) | 34 |
Race ring shape |
Angular Contact Ball Bearing |
Outer Diameter D (Φmm) |
180 |
Contact Angle |
15° |
Width B (mm) |
34 |
Monotaro ID |
12422448 |
Type of Product |
High-Precision Angular Contact Ball Bearing (Universal Combination/Single Type) |
Model No |
7220CTSULP4 |
Type |
Universal combination (single unit) |
Working Point a (mm) |
35.700000000000003 |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
NSK Ltd. |
Inner Diameter (mm) |
100 |
Basic Rated Load Cor (kN) |
127 |
Dimension R |
[Minimum] 2.1 mm |
Basic Rated Load Cr (kN) |
149 |
Nominal No. |
7220C |
Number |
【NSK】7220CTYNSULP4 |
Dimension r1 (min) (mm) |
1.1000000000000001 |
