| Race ring shape | Angular Contact Ball Bearing |
| Outer Diameter D (Φmm) | 150 |
| Contact Angle | 25° |
| Width B (mm) | 24 |
Race ring shape |
Angular Contact Ball Bearing |
Outer Diameter D (Φmm) |
150 |
Contact Angle |
25° |
Width B (mm) |
24 |
Monotaro ID |
12414441 |
Type of Product |
High-Precision Angular Contact Ball Bearing (Universal Combination/Single Type) |
Model No |
7020A5TSULP4 |
Type |
Universal combination (single unit) |
Working Point a (mm) |
41.1 |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
NSK Ltd. |
Inner Diameter (mm) |
100 |
Basic Rated Load Cor (kN) |
73.5 |
Dimension R |
1.5 min mm |
Basic Rated Load Cr (kN) |
71 |
Nominal No. |
7020A5 |
Number |
[NSK name number] 7020A5TYNSULP4 |
Dimension r1 (min) (mm) |
1 |
