Ships within 25 days
View
View
View
View
| Outer ring type | Flat |
| No. of Track Trains | Single row |
| Shield Shape | Open type |
| Race ring shape | Angular Contact Ball Bearing |
Outer ring type |
Flat |
No. of Track Trains |
Single row |
Shield Shape |
Open type |
Race ring shape |
Angular Contact Ball Bearing |
Material |
High Carbon Steel |
Outer Diameter D (Φmm) |
90 |
Rolling element material |
High Carbon Chromium Bearing Steel |
Contact Angle |
30° |
JIS grade |
0 |
Width B (mm) |
20 |
Monotaro ID |
7024656 |
Type of Product |
Single Row Angular Contact Ball Bearing 7200 Series |
Model No |
7210A |
Mass (g) |
466 |
Load direction |
Radial |
Working Point a (mm) |
30.2 |
Chamfer Dimension r1 (mm) |
0.6 (minimum) |
Basic load rating Cr (N) |
41500 |
Basic load rating Cor (N) |
31500 |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
NSK Ltd. |
Chamfer Dimension r (mm) |
1.1 (minimum) |
Allowable Speed (min-1[r.p.m]) Grease Lubrication |
8000 |
Allowable Speed (min-1 [r.p.m]) Oil Lubrication |
11000 |
Inner Diameter (mm) |
50 |
