| Bore Diameter (d) | 45 mm |
| Weight | 0.560 Kg |
| Bore Type | Round |
| Cage Type | Fiber Glass Reinforced |
Bore Diameter (d) |
45 mm |
Weight |
0.560 Kg |
Bore Type |
Round |
Cage Type |
Fiber Glass Reinforced |
Material |
High Carbon Chrome Steel |
Dynamic Load Rating |
40.00 kN |
Contact Angle |
30° |
Static Load Rating |
35.50 kN |
Width (B) |
16 mm (each bearing) |
Series |
7000 Series |
Type of Product |
Duplex Angular Contact Ball Bearing |
Model No |
7009DB |
Limiting Speed (Grease) |
7,500 RPM |
Enclosure |
Open |
Cage Material |
Nylon |
Limiting Speed (Oil) |
24,960 RPM |
Precision |
ISO Class 0 |
Seal Type |
Open |
Ball Material |
Steel |
Country of Origin |
India |
Bearing Type |
Angular Contact Ball Bearing |
Name of Manufacturer/Packer/Importer |
Mechanical Solutions |
Operating Temperature Range |
-40 ºC to 120 ºC |
Preload |
Normal |
Outside Diameter (D) |
75 mm |
Minimum Chamfer Radius (r) |
1 mm |
Minimum Chamfer Radius (r1) |
0.6 mm |
Configuration |
Duplex (Two Bearings) |
Radial Internal Clearance |
CN |
Arrangement |
Back-to-Back (DB) |
Total Width (2B) |
32 mm |
