| Outer ring type | Flat |
| No. of Track Trains | Double row |
| Shield Shape | Open type |
| Race ring shape | Angular Contact Ball Bearing |
Outer ring type |
Flat |
No. of Track Trains |
Double row |
Shield Shape |
Open type |
Race ring shape |
Angular Contact Ball Bearing |
Material |
High Carbon Steel |
Outer Diameter D (Φmm) |
72 |
Rolling element material |
High Carbon Chromium Bearing Steel |
JIS grade |
0 |
Basic static load rating Cor (N) |
28700 |
Width B (mm) |
27 |
Basic dynamic load rating Cr (N) |
39000 |
Monotaro ID |
8820567 |
Type of Product |
Double Row Angular Contact Ball Bearing 5200 Series |
Model No |
5207SC2 |
Load direction |
Radial |
Symbol of Internal Clearance Preload |
C2 |
Reference mass (g) |
460 |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
NTN Corporation |
Inner Diameter (mm) |
35 |
Permissible Speed (min-1) Oil Lubrication |
8000 |
Permissible Speed (min-1) Grease Lubrication |
6300 |
