| Type of Product | PCB Antenna |
| Impedance | 50 Ohms |
| Type | Passive Antenna |
| Style | Ceramic |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
PCB Antenna |
Impedance |
50 Ohms |
Type |
Passive Antenna |
Style |
Ceramic |
Bandwidth |
40 MHz |
Height |
0.6 mm |
Length |
3.2 mm |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
Abracon |
Ordering ID |
815-G0301-1575-T |
Manufacturer Part Number |
ACAG0301-1575-T |
Maximum Frequency |
1.575 GHz |
VSWR |
2 |
Gain (Db) |
4.18 dBi |
Minimum Operating Temperature |
-40°C |
Maximum Operating Temperature |
+85°C |
Series |
ACAG |
RoHS Compliant |
Yes |
Product Type |
GNSS Antennas - GPS, GLONASS, Galileo, Beidou |
Data Sheet |
https://www.mouser.in/datasheet/3/184/1/ACAG0301_1575_T.pdf |
Number of Bands |
1 Band |
Width |
1.6 mm |
Termination Style |
SMD/SMT |
Mounting Style |
PCB Mount |
Protocol - GPS, GLONASS |
GLONASS, GPS |
Mechanical Style |
Chip |
Application |
Weareable, Tablets, Mobile Devices, Navigation Devices, GPS Accessories |
Protocol - Sub GHz |
IoT |
Packaging Type |
Reel, Cut Tape, MouseReel |
