| Type of Product | PCB Antenna |
| Impedance | 50 Ohms |
| Type | Passive Antenna |
| Style | Ceramic |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
PCB Antenna |
Impedance |
50 Ohms |
Type |
Passive Antenna |
Style |
Ceramic |
Height |
2 mm |
Length |
25 mm |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
Abracon |
Ordering ID |
815-1575R2520ABDD7T |
Manufacturer Part Number |
APAE1575R2520ABDD7-T |
Maximum Frequency |
1.57542 GHz |
VSWR |
1.5 |
Gain (Db) |
4.3 dBic |
Centre Frequency |
1.575 GHz |
Minimum Operating Temperature |
-40°C |
Maximum Operating Temperature |
+85°C |
Series |
APAE |
RoHS Compliant |
Yes |
Product Type |
GNSS Antennas - GPS, GLONASS, Galileo, Beidou |
Data Sheet |
https://www.mouser.in/datasheet/3/184/1/APAE1575R2520ABDD7_T.pdf |
Number of Bands |
1 Band |
Width |
25 mm |
Termination Style |
Pin |
Mounting Style |
PCB Mount |
Protocol - GPS, GLONASS |
GPS |
Mechanical Style |
Patch |
Application |
Automotive Navigation, Marine Buoys, Surveying Equipment, Cell Phone, Laptop, Medical |
Packaging Type |
Tray |
