| Type of Product | PCB Antenna |
| Impedance | 50 Ohms |
| Type | Passive Antenna |
| Style | Ceramic |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
PCB Antenna |
Impedance |
50 Ohms |
Type |
Passive Antenna |
Style |
Ceramic |
Bandwidth |
28 MHz |
Height |
4 mm |
Length |
25.1 mm |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
Abracon |
Ordering ID |
815-APARM2504-SG3 |
Manufacturer Part Number |
APARM2504-SG3 |
Maximum Frequency |
1.602 GHz |
VSWR |
1.8 |
Minimum Frequency |
1.561 GHz |
Gain (Db) |
1.5 dBi, 3.5 dBi, 2.5 dBi |
Centre Frequency |
1.573 GHz |
Minimum Operating Temperature |
-40°C |
Maximum Operating Temperature |
+105°C |
Series |
APAR |
RoHS Compliant |
Yes By Exemption |
Product Type |
GNSS Antennas - GPS, GLONASS, Galileo, Beidou |
Data Sheet |
https://www.mouser.in/datasheet/3/184/1/APARM2504_SG3.pdf |
Number of Bands |
4 Band |
Width |
25.1 mm |
Termination Style |
Pin |
Mounting Style |
PCB Mount |
Protocol - GPS, GLONASS |
BEIDOU, Galileo, GLONASS, GNSS, GPS |
Mechanical Style |
Patch |
Application |
M2M, Remote Technology/Monitoring, Geofencing, Navigation, Surveying, Mapping Systems, Logistics, Automotive |
Protocol - Sub GHz |
IoT |
Packaging Type |
Bulk |
