| Type of Product | PCB Antenna |
| Impedance | 50 Ohms |
| Type | Embedded |
| Style | T-Bar Flex |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
PCB Antenna |
Impedance |
50 Ohms |
Type |
Embedded |
Style |
T-Bar Flex |
Height |
0.40 mm |
Length |
35.2 mm |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
KYOCERA AVX |
Ordering ID |
581-W1P35X8W4U100D3A |
Manufacturer Part Number |
W1P35X8W04-U100D3B0A |
Maximum Frequency |
2.48 GHz |
Minimum Frequency |
2.4 GHz |
Gain (Db) |
2.8 dBi |
Centre Frequency |
2.4 GHz |
Antenna Connector |
U.FL |
Series |
W1 Family |
RoHS Compliant |
Yes |
Product Type |
2.4GHz Antenna - 2.4GHz, 5GHz, Bluetooth, WiFi, WLAN, Zigbee |
Data Sheet |
https://datasheets.kyocera-avx.com/ethertronics/AVX-E_W1-Family.pdf |
Number of Bands |
1 Band |
Width |
8.5 mm |
Termination Style |
Connector |
Mounting Style |
Adhesive Mount |
Protocol - Bluetooth BLE - 802.15.1 |
Bluetooth |
Cable Type |
150 mm Coax |
Mechanical Style |
PCB Trace |
Application |
Access Points, Routers, Gateways, Embedded Design, M2M |
Protocol - WiFi - 802.11 |
WiFi, WLAN |
Packaging Type |
Bulk |
Protocol - ANT, Thread, Zigbee - 802.15.4 |
802.15.4 (ANT, Thread, Zigbee) |
