| Type of Product | PCB Antenna |
| Impedance | 50 Ohms |
| Type | Passive Antenna |
| Style | T-Panel Flex |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
PCB Antenna |
Impedance |
50 Ohms |
Type |
Passive Antenna |
Style |
T-Panel Flex |
Height |
8 mm |
Length |
45 mm |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
KYOCERA AVX |
Ordering ID |
581-1002089 |
Manufacturer Part Number |
1002089 |
Maximum Frequency |
2.7 GHz |
VSWR |
3.0:1, 3.0:1 |
Minimum Frequency |
698 MHz |
Gain (Db) |
5.1 dBi, 4.9 dBi |
Centre Frequency |
829 MHz, 2.205 GHz |
Antenna Connector |
SMA Male |
Minimum Operating Temperature |
-40°C |
Maximum Operating Temperature |
+85°C |
Series |
1002089 |
RoHS Compliant |
Yes |
Product Type |
Cellular Antennas - GSM, LTE, 2G/3G/4G/5G |
Data Sheet |
https://datasheets.kyocera-avx.com/ethertronics/AVX-E_1002089.pdf |
Number of Bands |
2 Band |
Width |
43.8 mm |
Termination Style |
Connector |
Mounting Style |
Adhesive Mount |
Power Rating |
2 W |
Protocol - Cellular, NBIoT, LTE |
Cellular (NBIoT, LTE), Cat-M |
Mechanical Style |
PCB Trace |
Application |
Medical Applications, Home Automation, Smart Metering, MWM, Firstnet, Automotive, Healthcare, POS, Tracking |
Protocol - WiFi - 802.11 |
LoRa, SigFox, LPWA, RPMA |
Packaging Type |
Waffle |
