| Type of Product | Outdoor Antenna |
| Impedance | 50 Ohms |
| Type | Passive Antenna |
| Style | Puck |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Outdoor Antenna |
Impedance |
50 Ohms |
Type |
Passive Antenna |
Style |
Puck |
Length |
38 mm |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
MAXTENA |
Ordering ID |
259-M1590HCT-LP-SM |
Manufacturer Part Number |
M1590HCT-LP-SM |
Maximum Frequency |
1.66 GHz |
VSWR |
8.4027777777777785E-2 |
Minimum Frequency |
1.525 GHz |
Gain (Db) |
2 dBic |
Centre Frequency |
1.5425 GHz, 1.6425 GHz |
Antenna Connector |
TNC |
Minimum Operating Temperature |
-40°C |
Maximum Operating Temperature |
+85°C |
IP Rating |
IP66 |
RoHS Compliant |
Yes |
Product Type |
GNSS Antennas - GPS, GLONASS, Galileo, Beidou |
Data Sheet |
https://maxtena.com/wpcontent/uploads/2021/07/M1590HCTLPSM.pdf |
Number of Bands |
2 Band |
Termination Style |
Connector |
Mounting Style |
Direct / Permanent Mount |
Protocol - GPS, GLONASS |
GLONASS, GPS |
Mechanical Style |
Helical |
Application |
Inmarsat IoT Applications, Vehicle Tracking, Fleet Tracking, Military, Security, Asset Tracking, Oil & Gas Industries, Navigation Devices, Mining Equipment, LBS Applications, M2M Applications, Law Enforcement |
Protocol - Sub GHz |
IoT |
Packaging Type |
Bulk |
