| Type of Product | PCB Antenna |
| Impedance | 50 Ohms |
| Type | Passive Antenna |
| Style | Chip |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
PCB Antenna |
Impedance |
50 Ohms |
Type |
Passive Antenna |
Style |
Chip |
Length |
5 mm |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
Molex |
Ordering ID |
538-146175-0001 |
Manufacturer Part Number |
146175-0001 |
Maximum Frequency |
5.85 GHz |
Minimum Frequency |
2.4 GHz |
Gain (Db) |
3 dB, 4.2 dB |
Centre Frequency |
2.45 GHz, 5.5 GHz |
Minimum Operating Temperature |
-40°C |
Maximum Operating Temperature |
+125°C |
Series |
146175 |
RoHS Compliant |
Yes |
Product Type |
2.4GHz Antenna - 2.4GHz, 5GHz, Bluetooth, WiFi, WLAN, Zigbee |
Data Sheet |
https://www.molex.com/en-us/products/part-detail/1461750001?display=pdf |
Number of Bands |
2 Band |
Width |
3.07 mm |
Termination Style |
SMD/SMT |
Mounting Style |
PCB Mount |
Power Rating |
2 W |
Protocol - Bluetooth BLE - 802.15.1 |
Bluetooth, BLE |
Mechanical Style |
Chip |
Application |
Industrial Use |
Protocol - Sub GHz |
IoT, ISM, U-NII |
Packaging Type |
Reel, Cut Tape, MouseReel |
Protocol - ANT, Thread, Zigbee - 802.15.4 |
802.15.4 (ANT, Thread, Zigbee), 802.16 |
