| Type of Product | PCB Antenna |
| Impedance | 50 Ohms |
| Type | Passive Antenna |
| Style | T-Bar Flex |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
PCB Antenna |
Impedance |
50 Ohms |
Type |
Passive Antenna |
Style |
T-Bar Flex |
Height |
0.1 mm |
Length |
53 mm |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
Molex |
Ordering ID |
538-146186-0050 |
Manufacturer Part Number |
146186-0050 |
Maximum Frequency |
6 GHz |
Minimum Frequency |
1.57542 GHz |
Gain (Db) |
4.2 dBi |
Centre Frequency |
1575.42 MHz, 1602 MHz, 2400 MHz, 2483.5 MHz, 4500 MHz, 5150 MHz, 5850 MHz |
Antenna Connector |
IPEX MHF |
Series |
146186 |
RoHS Compliant |
Yes |
Product Type |
Multiprotocol Antennas |
Data Sheet |
https://www.molex.com/en-us/products/part-detail/1461860050?display=pdf |
Number of Bands |
5 Band |
Width |
18 mm |
Termination Style |
Connector |
Mounting Style |
Adhesive Mount |
Protocol - Bluetooth BLE - 802.15.1 |
Bluetooth, BLE |
Cable Type |
50 mm Coax |
Protocol - GPS, GLONASS |
GLONASS, GPS |
Mechanical Style |
PCB Trace |
Application |
Industrial Use |
Protocol - Sub GHz |
ISM, U-NII |
Protocol - WiFi - 802.11 |
802.11, WiFi, WLAN |
Protocol - ANT, Thread, Zigbee - 802.15.4 |
802.15.4 (ANT, Thread, Zigbee), 802.16 |
