| Type of Product | PCB Antenna |
| Impedance | 50 Ohms |
| Type | Passive Antenna |
| Style | T-Bar Flex |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
PCB Antenna |
Impedance |
50 Ohms |
Type |
Passive Antenna |
Style |
T-Bar Flex |
Height |
0.16 mm |
Length |
147 mm |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
Molex |
Ordering ID |
538-207901-0200 |
Manufacturer Part Number |
207901-0200 |
Maximum Frequency |
6 GHz |
Minimum Frequency |
600 MHz |
Gain (Db) |
2.4 dBi, 4.6 dBi, 5 dBi |
Centre Frequency |
780 MHz, 2.25 GHz, 4.5 GHz |
Antenna Connector |
IPEX MHF |
Minimum Operating Temperature |
-40°C |
Maximum Operating Temperature |
+85°C |
Series |
207901 |
RoHS Compliant |
Yes |
Product Type |
Cellular Antennas - GSM, LTE, 2G/3G/4G/5G |
Data Sheet |
https://www.molex.com/en-us/products/part-detail-pdf/2079010200?display=pdf |
Number of Bands |
3 Band |
Width |
25 mm |
Termination Style |
Connector |
Mounting Style |
Adhesive Mount |
Power Rating |
2 W |
Cable Type |
200 mm Coax |
Protocol - Cellular, NBIoT, LTE |
2G/3G/4G/5G, Cellular (NBIoT, LTE), GSM, UMTS |
Mechanical Style |
PCB Trace |
Application |
Industrial Use |
