| Type of Product | PCB Antennas |
| Impedance | 50 Ohms |
| Type | Passive Antenna |
| Style | Composite |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
PCB Antennas |
Impedance |
50 Ohms |
Type |
Passive Antenna |
Style |
Composite |
Height |
3 mm |
Length |
40 mm |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
Pulse Electronics |
Ordering ID |
673-W3415 |
Manufacturer Part Number |
W3415 |
Maximum Frequency |
6 GHz |
Minimum Frequency |
617 MHz |
Gain (Db) |
- 1 dBi to 7 dBi |
Centre Frequency |
780 MHz, 868 MHz, 915 MHz, 1575 MHz, 1602 MHz, 1800 MHz, 1900 MHz, 2100 MHz, 2450 MHz, 3750 MHz, 5000 MHz, 5500 MHz |
Minimum Operating Temperature |
- 40°C |
Maximum Operating Temperature |
+ 85°C |
RoHS Compliant |
Yes |
Product Type |
Multiprotocol Antennas |
Data Sheet |
https://www.mouser.in/datasheet/3/203/1/W3415.pdf |
Number of Bands |
2 Band |
Width |
7 mm |
Termination Style |
SMD/SMT |
Mounting Style |
PCB Mount |
Protocol - ANT |
802.15.4 (ANT, Thread, Zigbee) |
Power Rating |
2 W |
Protocol - Bluetooth BLE - 802.15.1 |
Bluetooth, BLE |
Protocol - GPS, GLONASS |
GLONASS, GPS |
Protocol - Cellular, NBIoT, LTE |
2G/3G/4G/5G, Cellular (NBIoT, LTE), GSM, UMTS, DCS, PCS, WCDMA |
Mechanical Style |
PCB Trace |
Application |
Broadband Antenna |
Protocol - Sub GHz |
IoT, ISM, RFID, U-NII |
Protocol - WiFi - 802.11 |
802.11, LoRaWAN, SigFox, WiFi, WLAN, WiMAX |
