| Type of Product | PCB Antennas |
| Impedance | 50 Ohms |
| Type | Passive Antenna |
| Style | I-Panel Flex |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
PCB Antennas |
Impedance |
50 Ohms |
Type |
Passive Antenna |
Style |
I-Panel Flex |
Length |
26.8 mm |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
Pulse Electronics |
Ordering ID |
673-W3908B0100 |
Manufacturer Part Number |
W3908B0100 |
Maximum Frequency |
1.61 GHz |
Minimum Frequency |
1.56 GHz |
Gain (Db) |
0.27 dBi |
Centre Frequency |
1.575 GHz, 1.602 GHz |
Antenna Connector |
U.FL |
Minimum Operating Temperature |
- 40°C |
Maximum Operating Temperature |
+ 85°C |
RoHS Compliant |
Yes |
Product Type |
GNSS Antennas - GPS, GLONASS, Galileo, Beidou |
Data Sheet |
https://www.mouser.in/datasheet/3/508/1/W3908B0100.pdf |
Number of Bands |
1 Band |
Width |
20 mm |
Termination Style |
Connector |
Mounting Style |
Adhesive Mount |
Power Rating |
3 W |
Cable Type |
100 mm RF1.13 |
Protocol - GPS, GLONASS |
BEIDOU, GLONASS, GNSS, GPS |
Mechanical Style |
PCB Trace |
Application |
Satellite Receivers, Satellite Tracking, Location Base Services, Security, Transportation, IoT Devices |
