Ships within 45 days
View
View
View
View
| Type of Product | Vehicle Antennas |
| Impedance | 50 Ohms |
| Type | Passive Antenna |
| Style | Stubby |
Type of Product |
Vehicle Antennas |
Impedance |
50 Ohms |
Type |
Passive Antenna |
Style |
Stubby |
Length |
78.71 mm |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
Pulse Electronics |
Ordering ID |
673-SLPT698/2170DMN |
Manufacturer Part Number |
SLPT698/2170DMN |
Maximum Frequency |
2.7 GHz |
Minimum Frequency |
698 MHz |
Gain (Db) |
3.51 dBi, 4.81 dBi |
Centre Frequency |
830 MHz, 2.205 GHz |
Antenna Connector |
N Female |
Minimum Operating Temperature |
- 40°C |
Maximum Operating Temperature |
+ 85°C |
Series |
SLPT698/2170 |
IP Rating |
IP67 |
RoHS Compliant |
Yes |
Product Type |
Cellular Antennas - GSM, LTE, 2G/3G/4G/5G |
Number of Bands |
2 Band |
Termination Style |
Connector |
Mounting Style |
Direct / Permanent Mount |
Power Rating |
10 W |
Protocol - Cellular, NBIoT, LTE |
Cellular (NBIoT, LTE), UMTS |
Mechanical Style |
Whip |
Application |
Public Safety, LMR, ISM Applications, Bus, Rail, Transit, IoT Devices |
