| Type of Product | Indoor Antennas |
| Impedance | 50 Ohms |
| Type | Passive Antenna |
| Style | Radome |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Indoor Antennas |
Impedance |
50 Ohms |
Type |
Passive Antenna |
Style |
Radome |
Length |
260.48 mm |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
Radiall |
Ordering ID |
501-MD11-035 |
Manufacturer Part Number |
MD11-035 |
Maximum Frequency |
5.975 GHz |
VSWR |
3.0:1 |
Minimum Frequency |
5.15 GHz |
Gain (Db) |
6 dBi |
Centre Frequency |
5.5 GHz |
Antenna Connector |
N Female |
Minimum Operating Temperature |
- 40°C |
Maximum Operating Temperature |
+ 85°C |
Series |
MID GAIN COLINEAR ANTENNA |
RoHS Compliant |
Yes |
Product Type |
2.4GHz Antenna - 2.4GHz, 5GHz, Bluetooth, WiFi, WLAN, Zigbee |
Data Sheet |
https://www.mouser.in/datasheet/3/512/1/TDS_MD11_035.pdf |
Number of Bands |
1 Band |
Termination Style |
Connector |
Mounting Style |
Bracket Mount |
Power Rating |
10 W |
Protocol - Bluetooth BLE - 802.15.1 |
Bluetooth, BLE |
Protocol - Cellular, NBIoT, LTE |
5G, Cellular (NBIoT, LTE) |
Mechanical Style |
Collinear |
Application |
Wireless Applications |
Protocol - Sub GHz |
ISM |
Protocol - WiFi - 802.11 |
802.11, WLAN |
