| Type of Product | Outdoor Antennas |
| Impedance | 50 Ohms |
| Style | Radome |
| Bandwidth | 80 MHz, 60 MHz |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Outdoor Antennas |
Impedance |
50 Ohms |
Style |
Radome |
Bandwidth |
80 MHz, 60 MHz |
Height |
55 mm |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
SparkFun |
Ordering ID |
474-GPS-17751 |
Manufacturer Part Number |
GPS-17751 |
Maximum Frequency |
1.615 GHz |
VSWR |
2 |
Minimum Frequency |
1.198 GHz |
Gain (Db) |
5 dBi |
Centre Frequency |
1.238 GHz, 1.585 GHz |
Antenna Connector |
TNC Female |
Minimum Operating Temperature |
- 40°C |
Maximum Operating Temperature |
+ 85°C |
IP Rating |
IP67 |
Product Type |
Multiprotocol Antennas |
Electrical Type |
Active |
Data Sheet |
https://cdn.sparkfun.com/assets/b/4/6/d/e/TOP106_GNSS_Antenna.pdf |
Number of Bands |
2 Band |
Termination Style |
Connector |
Mounting Style |
Bracket Mount |
Protocol - GPS, GLONASS |
BEIDOU, Galileo, GLONASS, GNSS, GPS |
