| Type of Product | Outdoor Antennas |
| Impedance | 50 Ohms |
| Type | Passive Antenna |
| Style | Dome |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Outdoor Antennas |
Impedance |
50 Ohms |
Type |
Passive Antenna |
Style |
Dome |
Length |
29 mm |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
Taoglas |
Ordering ID |
960-IS04B301111 |
Manufacturer Part Number |
IS.04.B.301111 |
Maximum Frequency |
870 MHz |
VSWR |
2.5:1 |
Minimum Frequency |
868 MHz |
Gain (Db) |
1.98 dBi |
Centre Frequency |
868 MHz |
Antenna Connector |
SMA Male |
Minimum Operating Temperature |
- 40°C |
Maximum Operating Temperature |
+ 85°C |
Series |
Hercules |
IP Rating |
IP67, IP69K |
RoHS Compliant |
Yes |
Product Type |
ISM Antennas - ISM, MICS, UHF, VHF, UWB |
Data Sheet |
https://www.mouser.in/datasheet/3/942/1/IS.04.B.301111.pdf |
Number of Bands |
1 Band |
Termination Style |
Connector |
Mounting Style |
Direct / Permanent Mount |
Power Rating |
10 W |
Cable Type |
RG174 |
Protocol - Cellular, NBIoT, LTE |
Cellular (NBIoT, LTE), GSM, UMTS |
Mechanical Style |
Module |
Application |
Mesh Networks, Vehicle Assets, Outdoor Assets, ISM Application |
Protocol - Sub GHz |
ISM, RFID |
Protocol - WiFi - 802.11 |
LoRaWAN, SigFox |
