| Type of Product | Outdoor Antennas |
| Impedance | 50 Ohms |
| Type | MIMO |
| Height | 26 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Outdoor Antennas |
Impedance |
50 Ohms |
Type |
MIMO |
Height |
26 mm |
Length |
146 mm |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
Taoglas |
Ordering ID |
960-MA963ABIVW002WM |
Manufacturer Part Number |
MA963.A.BIVW.002.wm |
Maximum Frequency |
5.925 MHz |
Minimum Frequency |
617 MHz |
Gain (Db) |
4.76 dBi |
Centre Frequency |
657 MHz, 700 MHz, 800 MHz, 850 MHz, 900 MHz, 1561 MHz, 1575 MHz, 1602 MHz, 1800 MHz, 1900 MHz, 2100 MHz, 2500 MHz, 3400 MHz, 3500 MHz, 3600 MHz, 4400 MHz5200 MHz, 5800 MHz |
Antenna Connector |
SMA Male |
Minimum Operating Temperature |
- 40°C |
Maximum Operating Temperature |
+ 85°C |
IP Rating |
IP67 |
RoHS Compliant |
Yes |
Product Type |
Cellular Antennas - GSM, LTE, 2G/3G/4G/5G |
Data Sheet |
https://www.mouser.in/datasheet/3/942/1/MA963.A.BIVW.002.wm.pdf |
Number of Bands |
10 Band |
Width |
134 mm |
Termination Style |
Connector |
Mounting Style |
Bracket Mount |
Power Rating |
2 W |
Cable Type |
3 M TGC200 x 4 |
Protocol - GPS, GLONASS |
BEIDOU, Galileo, GLONASS, GPS, IRNSS |
Protocol - Cellular, NBIoT, LTE |
2G/3G/4G/5G, Cellular (NBIoT, LTE), GSM, UMTS, DCS, PCS, UMTS, GPRS, WCDMA, HSPA |
Mechanical Style |
Module |
Application |
IoT Gateway, Routers, HD Video Streaming, Transportation |
