| Type of Product | Outdoor Antennas |
| Impedance | 50 Ohms |
| Type | PIFA |
| Style | Button |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Outdoor Antennas |
Impedance |
50 Ohms |
Type |
PIFA |
Style |
Button |
Height |
14.3 mm |
Length |
19.8 mm |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
Taoglas |
Ordering ID |
960-WCM.01.0151W |
Manufacturer Part Number |
WCM.01.0151W |
Maximum Frequency |
2.5 GHz |
Minimum Frequency |
2.4 GHz |
Gain (Db) |
0.4 dBi |
Centre Frequency |
2.45 GHz |
Antenna Connector |
RP-SMA Male |
Minimum Operating Temperature |
- 40°C |
Maximum Operating Temperature |
+ 85°C |
Series |
Button |
IP Rating |
IP67 |
RoHS Compliant |
Yes |
Product Type |
2.4GHz Antenna - 2.4GHz, 5GHz, Bluetooth, WiFi, WLAN, Zigbee |
Data Sheet |
https://www.mouser.in/datasheet/3/942/1/WCM.01.0151W.pdf |
Number of Bands |
1 Band |
Width |
14.3 mm |
Termination Style |
Connector |
Mounting Style |
Connector |
Protocol - ANT |
802.15.4 (ANT, Thread, Zigbee) |
Power Rating |
10 W |
Protocol - Bluetooth BLE - 802.15.1 |
Bluetooth, BLE |
Mechanical Style |
Module |
Application |
Application Points, Routers, IoT Devices, M2M, Smart Home Application |
Protocol - Sub GHz |
IoT, ISM |
Protocol - WiFi - 802.11 |
802.11, WLAN, WiFi, WiMAX |
