| Type of Product | PCB Antennas |
| Impedance | 50 Ohms |
| Type | Active Antenna |
| Style | Ceramic |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
PCB Antennas |
Impedance |
50 Ohms |
Type |
Active Antenna |
Style |
Ceramic |
Bandwidth |
70 MHz |
Height |
2.3 mm |
Length |
45 mm |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
Taoglas |
Ordering ID |
960-ALA01070095A |
Manufacturer Part Number |
ALA.01.07.0095A |
Maximum Frequency |
1.576443 GHz |
VSWR |
2 |
Minimum Frequency |
1.574397 GHz |
Gain (Db) |
3.1 dBi |
Centre Frequency |
1.575 GHz |
Antenna Connector |
U.FL |
Minimum Operating Temperature |
- 40°C |
Maximum Operating Temperature |
+ 85°C |
RoHS Compliant |
Yes |
Product Type |
GNSS Antennas - GPS, GLONASS, Galileo, Beidou |
Data Sheet |
https://www.mouser.in/datasheet/3/942/1/ALA.01.07.0095A.pdf |
Number of Bands |
1 Band |
Width |
10 mm |
Termination Style |
Connector |
Mounting Style |
Adhesive Mount |
Cable Type |
95 mm RF1.13 |
Protocol - GPS, GLONASS |
Galileo, GPS |
Mechanical Style |
Loop |
Application |
Satellite Applications |
