| Type of Product | PCB Antennas |
| Impedance | 50 Ohms |
| Type | Passive Antenna |
| Height | 0.4 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
PCB Antennas |
Impedance |
50 Ohms |
Type |
Passive Antenna |
Height |
0.4 mm |
Length |
1.6 mm |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
TDK |
Ordering ID |
810-ANT162442DT-22A1 |
Manufacturer Part Number |
ANT162442DT-2200A1 |
Maximum Frequency |
5.85 GHz |
VSWR |
3 |
Minimum Frequency |
2.4 GHz |
Centre Frequency |
2.45 GHz, 5.5 GHz |
Minimum Operating Temperature |
- 40°C |
Maximum Operating Temperature |
+ 85°C |
Series |
ANT162442 |
RoHS Compliant |
Yes |
Product Type |
2.4GHz Antenna - 2.4GHz, 5GHz, Bluetooth, WiFi, WLAN, Zigbee |
Data Sheet |
https://product.tdk.com/system/files/dam/doc/product/rf/rf/antenna/catalog/rf_ant_ant162442dt-2200a1_summary_en.pdf?ref_disty=mouser |
Number of Bands |
2 Band |
Width |
0.8 mm |
Termination Style |
SMD/SMT |
Mounting Style |
PCB Mount |
Protocol - ANT |
802.15.4 (ANT, Thread, Zigbee) |
Protocol - Bluetooth BLE - 802.15.1 |
Bluetooth, BLE |
Mechanical Style |
Chip |
Protocol - Sub GHz |
IoT, ISM |
Protocol - WiFi - 802.11 |
802.11, WLAN, WiFi, WiFi 6E |
