| Type of Product | PCB Antennas |
| Impedance | 50 Ohms |
| Type | Embedded Dipole |
| Style | I-Bar Flex |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
PCB Antennas |
Impedance |
50 Ohms |
Type |
Embedded Dipole |
Style |
I-Bar Flex |
Height |
0.2 mm |
Length |
64 mm |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
TE Connectivity |
Ordering ID |
712-ANT-LPC-FPC-150 |
Manufacturer Part Number |
ANT-LPC-FPC-150 |
Maximum Frequency |
3.8 GHz |
VSWR |
8.2, 4.8, 1.7, 4.9, 3.5, 2.7, 3.1, 2 |
Minimum Frequency |
698 MHz |
Gain (Db) |
0.1 dBi, 3.7 dBi, 3.3 dBi, 2.2 dBi, 3.3 dBi, 3.9 dBi, 5 dBi, 5.7 dBi |
Centre Frequency |
868 MHz, 915 MHz |
Antenna Connector |
MHF1 / U.FL |
Minimum Operating Temperature |
- 40°C |
Maximum Operating Temperature |
+ 85°C |
Series |
FPC |
RoHS Compliant |
Yes |
Product Type |
Multiprotocol Antennas |
Data Sheet |
https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=ant-lpc-fpc-ccc-ds&DocType=Data+Sheet&DocLang=English&DocFormat=pdf&PartCntxt=ANT-LPC-FPC-150 |
Number of Bands |
8 Band |
Width |
17 mm |
Termination Style |
Connector |
Mounting Style |
Adhesive Mount |
Power Rating |
2 W |
Cable Type |
150 mm RF1.13 |
Mechanical Style |
PCB Trace |
Application |
Worldwide Cellular, Low Power Wide Area, ISM Applications, Global Navigation |
Protocol - Sub GHz |
IoT, ISM |
Protocol - WiFi - 802.11 |
WiFi, WLAN |
