| Type of Product | Outdoor Antennas |
| Impedance | 50 Ohms |
| Type | Shark Fin Antenna |
| Style | Shark Fin |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Outdoor Antennas |
Impedance |
50 Ohms |
Type |
Shark Fin Antenna |
Style |
Shark Fin |
Height |
84 mm |
Length |
245 mm |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
TE Connectivity |
Ordering ID |
239-L001044-03 |
Manufacturer Part Number |
L001044-03 |
Maximum Frequency |
6 GHz |
VSWR |
0.12569444444444444 |
Minimum Frequency |
617 MHz |
Gain (Db) |
6 dBi |
Antenna Connector |
SMA |
Minimum Operating Temperature |
- 40°C |
Maximum Operating Temperature |
+ 85°C |
Series |
FP40 auto |
IP Rating |
IP67, IP69K |
RoHS Compliant |
Yes (By Exemption) |
Data Sheet |
https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=C-L001044&DocType=Customer%20Drawing&DocLang=English&DocFormat=pdf&PartCntxt=L001044-01 |
Number of Bands |
6 Band |
Width |
63 mm |
Termination Style |
Connector |
Cable Type |
RG-174 |
Protocol - GPS, GLONASS |
GNSS |
Protocol - WiFi - 802.11 |
WiFi |
