| Type of Product | Indoor Antennas |
| Impedance | 50 Ohms |
| Type | Dipole |
| Style | Straight |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Indoor Antennas |
Impedance |
50 Ohms |
Type |
Dipole |
Style |
Straight |
Bandwidth |
250 MHz |
Length |
105 mm |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
TE Connectivity |
Ordering ID |
712-ANT-2.4-PW-QW |
Manufacturer Part Number |
ANT-2.4-PW-QW |
Maximum Frequency |
2.6 GHz |
VSWR |
1.9 |
Minimum Frequency |
2.35 GHz |
Gain (Db) |
1.6 dBi |
Centre Frequency |
2.45 GHz |
Minimum Operating Temperature |
- 40°C |
Maximum Operating Temperature |
+ 90°C |
Series |
QW |
RoHS Compliant |
Yes |
Product Type |
2.4GHz Antenna - 2.4GHz, 5GHz, Bluetooth, WiFi, WLAN, Zigbee |
Data Sheet |
https://4donline.ihs.com/images/VipMasterIC/IC/LNNC/LNNC-S-A0009748572/LNNC-S-A0009830647-1.pdf?hkey=CECEF36DEECDED6468708AAF2E19C0C6 |
Number of Bands |
1 Band |
Termination Style |
Connector |
Mounting Style |
Panel Mount |
Protocol - ANT |
802.15.4 (ANT, Thread, Zigbee), 802.16 |
Protocol - Bluetooth BLE - 802.15.1 |
Bluetooth, BLE |
Cable Type |
216 mm RG174 |
Protocol - Cellular, NBIoT, LTE |
Cellular (NBIoT, LTE) |
Mechanical Style |
Whip |
Application |
FirstNet/Public Safety, Sensing, Remote Monitoring, Handheld Devices |
Protocol - Sub GHz |
ISM |
Protocol - WiFi - 802.11 |
LoRaWAN, Sigfox, WiFi, WLAN |
